● Small light-emitting area and high-power density.
● Advanced packaging technology and fluorescent powder technology, providing worry-free heat dissipation.
● High brightness and good parameter consistency.
● Power, CCT and CRl can be customized (the CRl can reach up to 95).
● Suitable for flashlights, stage lights and landscape lighting, etc.
| Picture | Model | Input Power(W) | Current(A) | Typical Wavelength(nm) | Typical Flux(lm) | Luminous Size(mm) | CRI(Ra) | Dimensions L*W*H(mm) |
| HCOB2628-90-80-R00 | 90 | 6 | 8000 | 6200 | Φ3.8 | 70 | 26*28*5.5 |
| HCOB3640-200-205-R00 | 200 | 16 | 20500 | 13000 | 5.87*6.87 | 75 | 40*36*5.5 |
| HCOB4545-300-80-R00 | 300 | 6.5 | 8000 | 24500 | Φ11.5 | 70 | 45*45*5.5 |
| HCOB4560-300-56-R95 | 300 | 6.5 | 5600 | 16000 | Φ11.5 | 95 | 60*45*5.5 |
| HCOB4560-300-32-R95 | 300 | 6.5 | 6000 | 14300 | Φ11.5 | 95 | 60*45*5.5 |
| HCOB4545-400-80-R00 | 400 | 14 | 3200 | 30500 | 10.3*10 | 70 | 45*45*5.5 |
| HCOB4560-450-80-R00 | 450 | 12 | 8000 | 37500 | Φ14.5 | 70 | 60*45*5.5 |
| HCOB5266-300-3065-R95 | 300 | 7.5 | 3000 | 12000 | Φ14.5 | 95 | 66*52*5.5 |
| 300 | 7.5 | 6500 | 15000 | 95 | ||||
| MCOB100 | 115 | 5 | 15000 | 9300 | GOBO尺寸：16 焦距：18 | 70 | 44*35*33.2 |
| MCOB200 | 230 | 10 | 15000 | 17500 | GOBO尺寸：20 焦距：18 | 70 | 44*35*33.2 |
