● Concise light path: the simplest transmissive light path; small size gives designers more design space.
● Long range: With ф27mm lens, the range can reach 1300 meters @0.5lx.
● High brightness: Excite blue light to irradiate the fluorescent film to produce yellow fluorescence, with high conversion efficiency, which is 50% brighter than equivalent products on the market.
● Advanced materials: inorganic materials with high thermal conductivity and high heat resistance are used for the fluorescent sheet, without the risk of breakdown and the risk of blue light damage.
● High safety: The products have passed the safest class lEC 60825-1 Class 1 for laser blue light damage and the safest class for photobiological safety lEC 62471 Exempt.
Input Power(W) | Product | Model | CCT(K) | Voltage(V) | Current(A) | Typical Flux(lm) | Emitting Angle(°) |
| 10 | A010-D13 (low CCT) | A010-G-40-R00-0D13-00-0-4 | 3,900-4,400 | 3.7-5.2 | 2 | 460 | 66° |
| A010-D13 (high CCT) | A010-G-62-R65-0D13-00-0-1 | 5,300-8,000 | 3.7-5.2 | 2.3 | 700 | 66° | |
| A010-D13 (short size & high CCT) | A010-G-62-R65-0D13-00-0-2 | 5,300-6,700 | 3.7-5.2 | 2.3 | 670 | 66° | |
| A010-D13 (withdiffuser & high CCT) | A010-G-70-R65-0D13-00-0-B | 6,000-8,000 | 3.7-5.2 | 2.3 | 520 | 66° | |
| 15 | AF-DM015 | AF-DM015-65-D013-0 | 5,300-8,000 | 3.7-5.2 | 3 | 1,000 | 66° |
| AF-DM015 (with aperture) | AF-DM015-62-D013-B | 6,500-8,500 | 3.7-5.2 | 3 | 900 | 66° | |
| AF-DM015 (Non perforated flange with aperture) | AF-DM015-75-D21-B | 6,500-8,500 | 3.7-5.2 | 3 | 900 | 66° | |
| AF-DM015 (circular light spot) | AF–DM015-62-D016-1 | 5,300-8,000 | 3.7-5.2 | 3 | 850 | 3.3° | |
| 20 | FL-DM020 (with aperture) | FL -DM020-62-D027-A | 5,700-8,000 | 7.4-10.4 | 2.3 | 1,200 | 66° |
